T12V200-200-Plus-8-A160-LIKE NEW

  • Low stock - 4 items left
  • Inventory on the way
Regular price $699.99 Sale price$367.99
/
2 to 7 business days | Free Shipping across the U.S.

Automotive Grade A Battery Cells: Capable of 4,000-15,000 deep discharge cycles and delivering up to 10 years of reliable power.

Upgraded 200A BMS: Internal BMS has 5 protections, namely overcharging protection, over-discharging protection, over-current protection, short circuit protection, and high-temperature protection, which ensure the safety of the battery.

Larger Energy Capacity: Max. 200A continuous discharging & charging current, with the energy of 2560Wh can support multiple appliances.

Higher Energy Density: Measuring L21 x W8.2 x H8.5 Inches and 45.59lbs weight, up to 56.15Wh/lb energy density, while 12V 200Ah AGM battery (137lbs weight) with up to 17.52Wh/lb energy density.

Flexible Connection Options: Supports up to 16 batteries of 4 in series and 4 in parallel, Storing a massive 40.96kWh of energy to achieve energy freedom.

Quantity

  • 2 to 7 business days across the U.S.
  • 5 Years Warranty
  • 30 Days Hassle Free Returns
  • Product Description

  • Technical Details

  • FAQs

  • Customer Reviews

Timeusb 12V 200Ah lithium ion battery plus
Applications of Timeusb 12V 200Ah lithium ion battery Plus
3 Charging ways of 12V 200Ah lithium ion battery plus Timeusb
Installation Attention of Timeusb 12V 200Ah lithium ion battery Plus

Installation Attention

Do not place the front side or the top side of the battery facing downwards.

Timeusb 12V 200Ah lithium ion battery plus vs SLA Battery

Connection Reminder

1. From the same brand

2. the same type of battery with the same voltage, capacity & BMS

3. Purchased within 1 month

Capacity Expansion of Timeusb 12V 200Ah lithium ion battery Plus

Capacity Expansion

Maximum 16 x Timeusb 12.8V 200Ah Plus batteries in 4P4S connection could provide 40.96kW power and 40.96kWh energy.

Operating Temperature of Timeusb 12V 200Ah lithium ion battery Plus

Operating Temperature

Charge Temperature:32℉ to 122℉ (0℃ to 50℃)
Discharge Temperature:-4℉ to 140℉ (-20℃ to 60℃)
Storage Temperature:14℉ to 122℉ (-10℃ to 50℃)

Versatile for Your Needs

RV, Trailer, Van of Timeusb 12V 200Ah lithium ion battery plus

Born for RVs
The latest generation technology from Timeusb battery, gives you greater peace of mind on the road.

Camping of Timeusb 12V 200Ah lithium ion battery plus

Ultra energy and longer operating time
It was not only easy to work all day, but also a nice trip.

Home Solar system of Timeusb 12V 200Ah lithium ion battery plus

Perfect for Energy Backup
Timeusb 12V 200Ah PLUS battery provides 2560Wh usable power for your home.

Marine or Boat of Timeusb 12V 200Ah lithium ion battery plus

Longer life and less weight
Spend a great day on the water with your family.

PACKAGE CONTENTS:

1 x 12V 200Ah Plus LiFePO4 Battery

1 x Quick Start Guide

1 x Product Manual

2 x M8 Terminal Bolts

2 x Plastic Nut Caps

2 x Flat Washers

ATTENTION:

1. A charger is not included.

2. If a bolt is directly fastened or the thickness of the harness OT terminal piece used is less than 2 mm, add a flat washer for fastening.

NOTE:

This battery is not suitable for water pumps, electric jacks, electric stackers/lifts, pool vacuums, or similar loads. If you have any questions, please provide a specific product link, and we will check compatibility for you.

Technical Details

BATTERY
Cell Type:
LiFePO4 Prismatic
Warranty:
5 Years
Cycle Life:
4000 cycles at 100% DOD, 6000 cycles at 80% DOD, 15,000 cycles at 60% DOD
Nominal Voltage:
12.8V
Rated Capacity:
200Ah
Energy:
2560Wh
Max. Expansion (Parallel & Series):
4P (12V 800Ah) / 4S (48V 200Ah) / 4P4S (48V 800Ah)
Internal Resistance:
≤40mΩ
Certifications:
FCC/UL1973/CE/RoHS
BMS
BMS:
200A
Max. Continuous Output Power:
2560W
Max. Continuous Charge Current:
200A
Max. Continuous Discharge Current:
200A
Max. Discharge Current 5 Seconds:
400A
CHARGE
Charge Method:
CC/CV
Charge Voltage:
14.4V ± 0.2V
Recommend Charge Current:
40A
TEMPERATURE
Charge Temperature:
32℉ to 122℉ (0℃ to 50℃)
Discharge Temperature:
-4℉ to 140℉ (-20℃ to 60℃)
Storage Temperature:
14℉ to 122℉ (-10℃ to 50℃)
OTHERS
Terminals:
M8 bolts
Weight Approx.:
45.2 lbs
Size:
L21 x W8.2 x H8.5 in.
Housing Material:
ABS
Protection Class:
IP65

FAQs

Q: Can I use Timeusb LiFePO4 Lithium batteries as starting batteries?

A:

No. Timeusb LiFePO4 batteries are not designed to be used as starting batteries. They are specifically intended for energy storage and lack the Cold Cranking Amps (CCA) required for starting applications.

For more information, please refer to the "Deep Cycle VS Starting Battery" article.

Q: Can I use the Timeusb 12V 200Ah Plus LiFePO4 Battery for my trolling motor?

A:

Timeusb 12V lithium battery 200Ah Plus is compatible with trolling motor thrust between 70 and 100 pounds. If you have additional questions, we can provide you with recommendations based on your needs.

Q: What is the maximum number of Timeusb 12V 200Ah deep cycle battery Plus that can be connected?

A:

Timeusb 12V battery supports versatile connections including series, parallel and serial-parallel connections. You can connect up to 4 batteries in series (4S), 4 in parallel (4P) or 16 in series-parallel connection (4P4S).

Q: How do I store Timeusb LiFePO4 lithium batteries?

A:

It is recommended to store Timeusb LiFePO4 batteries at a 50% state of charge (SOC). For long-term storage, cycle the batteries at least once every six months. The ideal storage conditions are: 10℃~35℃ (50℉~95℉), 45%RH~75%RH.

Q: Are Timeusb LiFePO4 Lithium batteries safe?

A:

Yes. LiFePO4 is inherently safe and the most stable lithium-type battery available. Timeusb lithium cells are UL certified, meeting the highest safety and sustainability standards. Every Timeusb LiFePO4 battery includes an internal Battery Management System that protects against under-voltage during discharge, over-voltage during charge, over-current during discharge, over-temperature during both charge and discharge, and short circuits, safeguarding the battery cells from damage. Additionally, Timeusb LiFePO4 batteries have been tested to ensure they are free from fire and electric shock risks even in harsh environments.
